Import Gherkin Feature files

There are several ways to import Gherkin Feature files from Cucumber.

What is Gherkin?

Gherkin is the format for Cucumber specifications. It is a domain specific language which helps you to describe business behavior without the need to go into detail of implementation. This text acts as documentation and skeleton of your automated tests. Gherkin is based on TreeTop Grammar which exists in 37+ languages. Therefore you can write your gherkin in 37+ spoken languages.

TestQuality CLI

You can use TestQuality CLI tool, as shown in this video.

We are working on getting the video demo as soon as possible.

TestQuality web application

  1. Choose Administration -> Import Options or navigate to Import
  2. Either drag or click to select Gherkin Feature file.
  3. Select the project and test plan to which you want to attach data.
A screenshot of a cell phone

Description automatically generated
A screenshot of a social media post

Description automatically generated

Fill in your user name and password. Then for any job, enter Configure. Select “Add post-build action”, and select TestQuality Updater. Select the Project, Test Plan and location of test results file. On your next build check TestQuality to set see Test Plan changes and Test Plan Run added.

REST

Gherkin feature files can be uploaded via TestQuality REST interface. The following example shows how to do this via curl a popular command line tool.

Step 1, Authenticating

TestQuality API uses OAuth2 for authentication. Please contact Support to obtain a client key for using the API.

curl -X POST \

-H ‘Content-Type: application/json’ \

-H ‘Accept: application/vnd.testquality.v1+json’ \

-d ‘{“client_id”: “2”,”client_secret”:”23MBS86X7JrK4Mrr1mk4PKfo6r4zRVx9MrmxXfdX”, “grant_type”:”password”, “username”:”your@email.com”, “password”:”your_password”}’ \

https://api.testquality.com/api/oauth/access_token

This command will return your token.

{

  “user_id”:7,

  “beta_mode”: true,

  “verification_ends_at”: “null”,

  “trial_ends_at”: “2017-11-08T21:42:26+00:00”,

  “subscription_ends_at”: null,

  “client_id”: 1,

  “client_name”: “tq”,

  “token_type”:”Bearer”,

  “expires_in”:86400,

  “access_token”:”eyJ0eXAiOiJKV1QiLCJhbGciOiJSUzI1NiIsImp0aSI6IjE2NDU4MmE5YWQwZjIwOTBjNDI2OTMwMWQ5MmUyYzQ4NDQwNTkxZTNhNmE5ZmNhMzVmYjg0ZmY1NGQ4YzAwOTI4OTdmZDYxZTk4NTlhNTExIn0.eyJhdWQiOiIyIiwianRpIjoiMTY0NTgyYTlhZDBmMjA5MGM0MjY5MzAxZDkyZTJjNDg0NDA1OTFlM2E2YTlmY2EzNWZiODRmZjU0ZDhjMDA5Mjg5N2ZkNjFlOTg1OWE1MTEiLCJpYXQiOjE1MDg4ODEzNDUsIm5iZiI6MTUwODg4MTM0NSwiZXhwIjoxNTA4OTY3NzQ1LCJzdWIiOiI3Iiwic2NvcGVzIjpbXX0.n9UGtd4UpN2hfFi4pnAcossv_24J0IJjcFHoPNETbIXuJcZUziLa1S1iJjvqklq3J4GX2GzIG0l0Mwh6Ek_lrXej0aBxB-j1eYz2_VtTvr92IyaMcJVQ6iVb_y5WEIjM8K_xxseFFUQB2cBUzTgBudi1FjhSVby7M7DoEdzsRkiT5RlbszwjpWhrcvs9YD08u-m286AjmWeOdD1vPA837wh0eU1Ay5r_sWMdlmcmTdWHcCkqz50Z12DH3cIwtxByi8nYdYCwnW0ubcNoKRaY8FDjWUQBCfVezYjHjIzQy82FbvZxwRWaJ2KKeo7f6HZT3Wt-xUis-ci0Ac2z4D8TkLgifBPeloCNUbAl2mNDp3RlOCGwWcHPnZUS7282V887mF6OHWSzGJ2uzKqC_EgJPGmz2-CeILpm13wO-cy_0DIiTtjCZCezpLJt95El5NRVOouymSJHCgRrCZ0y33-iy9EJqYiTb1m6QSyyXd3aH90rPJZ_VukKyrPLHHMrMaggp_mEv8Dx49w_6My297J8ew9bqO9y_-IO2IU5O_fmtJFWz6LPcoiw4a4954G6O_XBqjD9BzuYej34jjwmmPLkCOGlo-U4NW70QdTqQ-v61Jij7L9KV69nlTFoYriAB9RJC9ncxXyw1Oi_I4OeYYXIQYe1WXyUSu3z2rRvYy678Xg”,

  “refresh_token”:”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”

}

The access token is in the “access_token” property.

Step 2, Obtain Test Plan ID

To obtain the Test Plan identification number, we will query using the plan name (could use key if you prefer).

curl -X GET \

-H ‘Authorization: Bearer eyJ0eXAiOiJKV1QiLCJhbGciOiJSUzI1NiIsImp0aSI6IjE2NDU4MmE5YWQwZjIwOTBjNDI2OTMwMWQ5MmUyYzQ4NDQwNTkxZTNhNmE5ZmNhMzVmYjg0ZmY1NGQ4YzAwOTI4OTdmZDYxZTk4NTlhNTExIn0.eyJhdWQiOiIyIiwianRpIjoiMTY0NTgyYTlhZDBmMjA5MGM0MjY5MzAxZDkyZTJjNDg0NDA1OTFlM2E2YTlmY2EzNWZiODRmZjU0ZDhjMDA5Mjg5N2ZkNjFlOTg1OWE1MTEiLCJpYXQiOjE1MDg4ODEzNDUsIm5iZiI6MTUwODg4MTM0NSwiZXhwIjoxNTA4OTY3NzQ1LCJzdWIiOiI3Iiwic2NvcGVzIjpbXX0.n9UGtd4UpN2hfFi4pnAcossv_24J0IJjcFHoPNETbIXuJcZUziLa1S1iJjvqklq3J4GX2GzIG0l0Mwh6Ek_lrXej0aBxB-j1eYz2_VtTvr92IyaMcJVQ6iVb_y5WEIjM8K_xxseFFUQB2cBUzTgBudi1FjhSVby7M7DoEdzsRkiT5RlbszwjpWhrcvs9YD08u-m286AjmWeOdD1vPA837wh0eU1Ay5r_sWMdlmcmTdWHcCkqz50Z12DH3cIwtxByi8nYdYCwnW0ubcNoKRaY8FDjWUQBCfVezYjHjIzQy82FbvZxwRWaJ2KKeo7f6HZT3Wt-xUis-ci0Ac2z4D8TkLgifBPeloCNUbAl2mNDp3RlOCGwWcHPnZUS7282V887mF6OHWSzGJ2uzKqC_EgJPGmz2-CeILpm13wO-cy_0DIiTtjCZCezpLJt95El5NRVOouymSJHCgRrCZ0y33-iy9EJqYiTb1m6QSyyXd3aH90rPJZ_VukKyrPLHHMrMaggp_mEv8Dx49w_6My297J8ew9bqO9y_-IO2IU5O_fmtJFWz6LPcoiw4a4954G6O_XBqjD9BzuYej34jjwmmPLkCOGlo-U4NW70QdTqQ-v61Jij7L9KV69nlTFoYriAB9RJC9ncxXyw1Oi_I4OeYYXIQYe1WXyUSu3z2rRvYy678Xg’ \

-H ‘Content-Type: application/json’ \

-H ‘Accept: application/vnd.testquality.v1+json’ \

https://api.testquality.com/api/plan?name=Smoke

This will return a result of:

{

  “current_page”:1,

  “data”:[

    {

      “id”:53,

      “created_by”:7,

      “updated_by”:7,

      “epoch”:1,

      “project_id”:22,

      “assigned_to_tester”:7,

      “virtual”:null,

      “name”:”Smoke”,

      “description”:”Basic Smoke Tests”,

      “client_id”:1,

      “key”:18,

      “retain_runs”:0,

      “created_at”:”2017-09-28T23:15:32.533000+00:00″,

      “updated_at”:”2017-10-24T14:52:40.938000+00:00″,

      “metadata_model”:”Plan”

    }

  ],

  “first_page_url”:”http:\/\/testquality:8001\/api\/plan?name=Smoke&page=1″,

  “from”:1,

  “last_page”:1,

  “last_page_url”:”http:\/\/testquality:8001\/api\/plan?name=Smoke&page=1″,

  “next_page_url”:null,”path”:”http:\/\/testquality:8001\/api\/plan”,

  “per_page”:15,

  “prev_page_url”:null,

  “to”:1,

  “total”:1

}

We just need the id, in this case 53.

Step 3, Upload Gherkin Feature File

The curl form function that is used to upload file.

curl -X POST \

-F ‘file=@/Users/jamespitts/Dev/testQualityApp/gherkin/dashboard.feature’ \

-H ‘Authorization: Bearer eyJ0eXAiOiJKV1QiLCJhbGciOiJSUzI1NiIsImp0aSI6ImQ1OTdhMjNiNjY2NDMwYWMyYjM5MWRhMDRkYzNjYjhiMzZlNmZmNzRmMTYxOGNiYTM3MjQ3NjNkMjIxMDMyZDk2ZDIyM2NkM2Q5MWRiNjc0In0.eyJhdWQiOiIyIiwianRpIjoiZDU5N2EyM2I2NjY0MzBhYzJiMzkxZGEwNGRjM2NiOGIzNmU2ZmY3NGYxNjE4Y2JhMzcyNDc2M2QyMjEwMzJkOTZkMjIzY2QzZDkxZGI2NzQiLCJpYXQiOjE1MDg4ODIwNTIsIm5iZiI6MTUwODg4MjA1MiwiZXhwIjoxNTA4OTY4NDUyLCJzdWIiOiI3Iiwic2NvcGVzIjpbXX0.RQl8acC5HtfI7LGCYdrEPRkgeJ52-hRU9-sN7o1Rc-ITrnynlMdd60J8oDqRGAfQrppKx7MEM4S9ygznpzsNrHcqbKPnTnu6tfqws6k1kJcglGlgTXH_YRIbR8V7kao_pcUouj5tUgNLnKWVbHRBpoKTy1xO9nQZEjtWkWCkZCDg0xd6MRtyyYDINLf-K9QQZtpbqKLBPWQVYKk74YoDA75S19HzbcQQhI1J7XqqizWdaUmfzsbK74GcS5ve3v_VYeXafOnuC8dSmytsOoFohODJz9urzKtIKVKiD-tXXGf7opLKrW44XJVFrZ9kImYujC6bo4Bberg-1UGvScgd6AJ2p2NueMUiUGbs7CYEW-DP_12viVnxGgfiMhmwBmjjwgHlsLGZG8JzUIL_gHRzpyGTTQY56RAXuAslMGDct5WmEz2ErQxWucLf1q294t6PjCXPICIUL41IqKQMe_X0koPyA1RzcJEom9Sk5T3KyMg0bJnYICX0lseVT7ul2tMjP8CWOCvVVpMI81OcCoRuP9Oxw-xYZsDT7hY1RM1phrHk0gR5tPZyLzd_LZP7DmlENbjA0yioqBlZTBSGL-Rvbn0GZPREc87Fr0K5YB8NsAKgcdG-i6U7Y08Bw2kvTrCz2ly08J6qM7FJADP0_4Budh6CsuzaNxj-iWqB_lr301U’ \

-H ‘Accept: application/vnd.testquality.v1+json’ \

https://api.testquality.com/api/plan/53/import_feature

Note: 53 in /plan/53/import_feature

Success!

{

  “plan_url”:”http:\/\/localhost:3000\/project\/36\/plan\/53″,

  “suites”:4,

  “tests”:36

}

Other Scripts

This flow can easily be used in gulp/grunt using “request” framework. Or PowerShell, basically anything that supports REST API.
